- Pre-Filter: 10 µm efficiency (Washable)
- HEPA Filter: ≥99.97% @ 0.3 microns
- Air Velocity at Grill: 90 ± 20 FPM
- Air Flow Direction: Reverse horizontal laminar flow
Reverse Laminar Air Flow
At our facility, we design high-performance Reverse Laminar Air Flow (RLAF) machines tailored for use in contamination-sensitive environments such as pharmaceutical, biotech, and research industries. These units provide localized clean air by directing HEPA-filtered air in a reverse horizontal flow to ensure product and personnel protection from particulate contamination.
What We Offer
Features
HEPA Filter Integration
Equipped with HEPA filters (99.97% @ 0.3µ) to ensure particle-free airflow for sterile operations.
Reverse Laminar Flow
Provides a uniform, reverse airflow pattern to contain contaminants and protect workspaces.
Stainless Steel Build
Fabricated using SS 304 for corrosion resistance, cleanability, and pharmaceutical-grade hygiene.
User-Friendly Operation
Integrated with control panel, pressure gauges, and light indicators for safe, easy monitoring.
Specifications
Filtration System
Electrical & Operating Details
- Power Supply: 230V ±10%, 50Hz
- Motor Blower: Dynamically balanced, low vibration
- Noise Level: ≤65 dB at 1 meter distance
- Lighting: LED / Fluorescent Lamp with UV (optional)
Construction & Material
- Body Material: Stainless Steel 304 (Matt finish)
- Viewing Window: Acrylic / Toughened Glass
- Work Surface: SS perforated or solid top
- Caster Wheels: Lockable, heavy-duty PU type
Additional Information
- Applications: Weighing, sampling & dispensing operations in cleanrooms
- Standard Sizes: 2ft / 3ft / 4ft / 6ft (custom sizes available)
- Standards Compliance: ISO 14644-1 Class 5, GMP, WHO
- Origin: Made in India
